The KardiaMobile 6L from AliveCor produces a medical grade 6 lead ECG recording that gives you and your Doctor a more complete view of your heart using a free iOS and Android App. It's the first and only FDA cleared and CE-marked six lead personal ECG that will detect Atrial Fibrillation or Normal heart rhythm anytime, anywhere.
Six leads of ECG data gives your doctor a more complete view of your heart, and the ability to identify other cardiac arrhythmias including atrial flutter, heart block and PVCs.
The KardiaMobile ECG has 2 electrodes in the front and one on the back. The two electrodes on the top are for your fingers, and the one on the bottom to contact the skin of your left leg. To record a 6 lead ECG hold the KardiaMobile 6L in your hands, placing your fingers on the front electrodes then touch the third electrode to the skin of your left knee or ankle. It's that easy. It can also be used to record a 1 Lead ECG giving you additional added flexibility.
What six leads does it record? The KardiaMobile 6L displays and records 30 seconds of Lead I, Lead II, Lead III, aVR, aVL and aVF ECG in real time to your phone or tablet.
ECGs are stored in the app which at the end of the recording displays the ECG trace, heart rate and classifies the recording into 1 of the following categories.
Atrial Fibrillation. The clinically validated algorithm will notify you to the presence of possible atrial fibrillation. If AF is detected, you will see the message "Possible AF Detected."
Normal. If no rhythm abnormalities are detected, you will receive the message 'Normal'. The shape, timing and duration of each beat is considered normal.
Bradycardia means your heart rate is below 50 beats per minute and the shape, timing and duration of each beat is normal.
Tachycardia means your heart rate is faster than 100 beats per minute and the shape, timing and duration of each beat is considered normal.
Unclassified means the recording is not normal, possibly AF, Tachycardia or Bradycardia and may be caused by other arrhythmias.
Unreadable means you didn't have a proper ECG recording for analysis and there is too much interferance in your recording.
Never before has more heart health information been available at your fingertips. Share detailed 6-lead ECGs with your Doctor for a better view of your heart or just record a 6 lead ECG for your own peace of mind. It works with most smartphones and tablets on Android and iOS. KardiaMobile 6L is not tested or recommended for use with pacemakers and ICDs.
The free Kardia Basic App provides local storage of multiple ECGs in the Kardia App. A user can view a complete history of the ECG's they have recorded on their device. Any stored ECG can also be printed or e-mailed as a PDF directly from the mobile device.
The optional chargeable KardiaCare membership adds additional features to the App including a monthly heart health report, cloud based storage, medication tracking a historical view of heart health data and Advanced Determinations. Advanced Determinations can detect three additional arrhythmias:
Sinus Rhythm with Premature Ventricular Contractions (PVCs)
Sinus Rhythm with Supraventricular Ectopy (SVE)
Sinus Rhythm with Wide QRS
A free one month trial of KardiaCare membership is included when you first set up your account. After one month if you wish to continue with your KardiaCare membership the cost is £99 per year or £179 for 2 years. If you don't want to continue with your KardiaCare membership, the app changes back to the Basic App with no monthly charge.
The KardiaMobile 6L does not come with a Phone Clip attachment plate or Carry Pod. We recommend you purchase a 6L Carry Pod or 6L Phone Clip when ordering. The iPhone 5 and iPhone 5c are not compatible with the KardiaMobile 6L.
Buy with confidence direct from PMS Instruments an official AliveCor UK authorised Distributor.
Record a medical grade 6 lead or 1 lead ECG
Take unlimited medical-grade ECGs - anytime, anywhere. No subscription required
Records Lead I, II, III, aVR, aVL and aVF ECG in realtime
Designed and engineered by AliveCor in California, USA
Connects using Bluetooth Low Energy Technology
1 metre wireless range
Uses 3 stainless steel electrodes
No messy gels or wires
Dimensions 9.0 cm x 3.0 cm x 0.72 cm
Weight 24 grams
Approximately 12 months (200 hours) operating time on one CR2016 battery
Perfect for opportunistic screening of Atrial Fibrillation (AF) by patients or clinicians
Email a PDF or print an ECG from your device
Recording duration from 30 sec to 5 mins
IP22 ingress protection
Professional, CE and FDA approved clinically validated medical device
Not recommended for use with a cardiac pacemaker, ICDs, or other implanted electronic devices.
One 3 volt CR2016 coin cell battery
24 month warranty
Quick start guide
Alivecor after sales phone and email support
Manufacturers part number AC-019-NUA-A
